| Camera | |
| Image Sensor | 1/2.8″ Progressive Scan CMOS |
| Min. Illumination | Color: 0.001 Lux @ (F1.0, AGC ON) |
| Shutter Speed | 1/3 s to 1/100,000 s |
| Angle Adjustment | Pan: 0° to 360°, tilt: 0° to 90°, rotate: 0° to 360° |
| Slow Shutter | Yes |
| P/N | P/N |
| WDR | Digital WDR |
| Lens | |
| Lens Type & FOV | · 2.8 mm, horizontal FOV 107, vertical FOV 56, diagonal FOV 127
· 4 mm, horizontal FOV 84, vertical FOV 45, diagonal FOV 99 |
| Aperture | F1.0 |
| Aperture Type | Fixed |
| Depth of Focus | · 2.8 mm: 1.7 m to ∞
· 4 mm: 2.1 m to ∞ |
| Lens Mount | M12 |
| Network | |
| Protocols | TCP/IP, ICMP, HTTP, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, NTP, UPnP, SMTP, IGMP, QoS, IPv6, UDP, Bonjour, SSL/TLS |
| User/Host | Up to 32 users. 3 user levels: administrator, operator and user |
| Client | iVMS-4200, Hik-Connect, Hik-Central |
| Video | |
| Main Stream | · 50Hz: 25fps (1920 × 1080, 1280 × 960, 1280 × 720)
· 60Hz: 30fps (1920 × 1080, 1280 × 960, 1280 × 720) |
| Sub Stream | · 50Hz: 25fps (640 × 480, 640 × 360, 320 × 240)
· 60Hz: 30fps (640 × 480, 640 × 360, 320 × 240) |
| Video Compression | · Main stream: H.265+/H.265/H.264+/H.264
· Sub-stream: H.265/H.264/MJPEG |
| H.264 Type | Baseline Profile/Main Profile |
| H.265 Type | Main Profile |
| Video Bit Rate | 32 Kbps to 8 Mbps |
| Image | |
| Image Enhancement | BLC, HLC, 3D DNR |
| Image Setting | Rotate mode, saturation, brightness, contrast, sharpness, gain, white balance adjustable by client software or web browser |
| Day/Night Switch | Day, Night, Auto, Schedule |
